GREAT CONDITION WELL MADE FOR POWERLOCK HSK AND CONVENTIONAL CUTTERS. (see notes)
Working cap. Length 9-3/8"; cutting circle 4" to 11-1/2"
Hydraulic grinding wheel clamping.
Grinding wheel speed 1,500-3,000 RPM's
Grinding spindle 1.5 HP
Cooling system with hoses 0.5 HP pump and 13 gal. tank
Grinding clearance angles: Radial at back 10-30°, Lateral in manual 0-20°: straight knife 60°.
Performance package: Motorized positioning of grinding wheel angles - Side clearance, motorized advance to the knife and pneumatic adjustment for back clearance angle. Machine light
HSK Package: Tool holder with manual clamping; pivoting right and left for head alignment: Radial table clamping: max. tool width of 9-1/2" (240mm) and max. tool dia. of 9-7/8" (250mm); HSK tool adaptor for conventional tool grinding.
Includes: Reverse wheel rotation for Carbide Grinding
Note: Cleaned and checked with tools included.
