Description
USED GANNOMAT MODEL JUNIOR 323 FRAMEDRILLING and MORTISING MACHINE EXHAUST DEVICE 80MM DIA 1 PAIR OF WORK PIECE SUPPORTS SWIVEL MOUNTED (left & right)1 BASIC RULER 1100 MM AND 2 EXTENSON RULER 1000 MM with 6 TILT STOPS ROTATABLE INDEXING BAR, pitch 12/16/25`4 CASTERS TO MAKE MACHINE MOBILE 2 SPEED MOTOR, 1400/2400 RPM, 400V, 3PH, 60HZVIA BUILT IN TRANSFORMER, PNEUMATIC FEED OPERATED BY FOOTPEDAL/VALVE AND SELECTOR SWITCH FOR MANUAL AND AUTOMATIC FUNCTION CENTERING DEVICE, MAX ADJUST 120MM WIDE ADAPTER FOR DRILL HEAD. MAX DRILL BIT LENGTH IS 100MM 5 SPINDLE DRILL HEAD, PITCH 32MM CENTER TO CENTER (can be rotated 0 to 90 deg) UPCHARGE FOR DRILLING DEPTH MAX. 200MM
