Low hour, clean unit. Priced to sell!
Minimum material length; 250 mm (10”)
Material thickness
Minimum; 10 mm (.39”)
Maximum; 100 mm (4")
Distance between blade and column; 466 mm (18.75")
Number of hold-down rollers; (6)
Work table height; 850 mm (32.5”)
Saw arbor motor; 15 HP IE3
Saw arbor speed; 4100 RPM
Saw blade diameter; 250-305 mm (10“-12“)
Saw arbor diameter; 25.4 mm (1”)
Variable feed speed; 15 - 131 FPM
Feed motor; 1 HP
Table area (w x l) 1100 mm (43”) x 1330 mm (52”)
Machines Dimension; 2469 x 1150 x 1403 mm (97 x 45 x 55")
Machine weight; 2,538 lbs
Dust extraction; 614 CFM at 4,500 FPM
Dust Extraction Port; 125 mm (5")
Laser Line mounted
Chain is in incredible condition. The machine is ready to work
