Main features of the machine: - Single-head drilling machine for drilling at an angle range of 0 - 90° - Securing clamps allow quick panel positioning without adjustment - Spindles adapted for quick couplings - Fast and precise adjustments and drilling - Italian-made 2016
Standard machine equipment: - 2 aluminum rulers, 1.5 m long (right and left), each with four stops - 5 quick couplings - Wooden crate for safe transport of the machine Fpebbh Ecox Rqk Isn Eoc
ADVANTAGES
- Drilling vertically/horizontally/at an angle - Multiple spindles - New machine - CE certificate - Robust - Professional
TECHNICAL DATA
- Number of spindles: 23 - Distance between the first and last drill bit: 704 mm - Distance between centers of adjacent spindles: 32 mm - Max. size of workpiece: 950 x 3000 mm - Max. workpiece thickness: 60 mm - Max. drilling depth: 65 mm - Number of pneumatic clamps: 2 - Working pressure: 6-7 bar - Air consumption: 10 l/cycle - Motor power: 1.5 kW - Noise level: 76.1 dB - Spindle speed: 2800 rpm - Overall dimensions: 1235/950/1310 mm - Weight: 310 kg
PICK UP AVAILABLE. FREIGHT OPTIONS ARE NOT INCLUDED. ACCEPTING ACH, ZELLE AND CHECK PAYMENTS. PLEASE EMAIL US FOR MORE INFORMATION. THANK YOU!
