Specs:
Motor: 3 HP, 220V, single-phase, TEFC capacitor start-induction
RPM: 1725
Precision-ground cast-iron table size: 26-3/4″ x 19″ x 1-1/2″ thick
Floor to table height: 37-1/2″
Cutting capacity/throat: 18-1/4″
Maximum cutting height: 12″
Blade length: 143″
Blade length range: 141-1/2″ – 143″
Blade width range: 1/8″ – 1-1/4″
2 Blade speeds: 1700, 3500 FPM
Wheels: computer-balanced cast-iron with polyurethane tires
Wheel covers: pre-formed, hinged steel
Blade guides: dual ball bearings with full enclosure protection
Motor bearings: sealed and permanently lubricated
Blade tension indicator
Rack-and-pinion table tilt mechanism
Computer-balanced cast-iron wheels
Height scale measurement
Fence with scale and magnifying window
Deluxe cast-iron fence with deluxe extruded-aluminum resaw fence
Miter gauge
Two 4″ dust ports
Table tilt: 5° left, 45° right
Quick-change blade release/tensioning
Rack-and-pinion upper guide adjustment
Foot brake
Cast-iron trunnion
Key lockout safety switch
Includes 3/4″ hook-style blade
Overall size: 36″W x 76″H x 32″D
Approximate shipping weight: 500 lbs
Features:
Quick-change blade release/tensioning
Blade tension indicator
Rack-and-pinion table tilt mechanism
Computer-balanced cast-iron wheels
Height scale measurement
Fence with scale and magnifying window
Deluxe cast-iron fence with deluxe extruded-aluminum resaw fence
Miter gauge
Two 4″ dust ports
Rack-and-pinion upper guide adjustment
Foot brake
Cast-iron trunnion
Key lockout safety switch
Includes 3/4″ hook-style blade
NOTES:
🔥 10 BLADE PRO MACHINERY
📞 1‑833‑410‑2523
📞 1‑833‑4‑10BLADE
📸 IG: @10bladepromachine
📘 FB: facebook.com/10BladeProMachinery
🚚 Immediate Pickup — No Tax — No Freight — No Regrets
Open Box. Stored indoors. Unused. Sold exactly as received
