Specs:
Helical cutterhead with triple V-belt drive
2-speed chain-driven automatic feed rollers
Hardened anti-kickback fingers
Precision-ground cast-iron table and extension wings
Locking table
Magnetic switch overload protection
Ball bearing return rollers
Depth scales in both inch and metric
Pedestal-mounted control panel
Motor: 3 HP, 240V, 15A, single-phase
Maximum cutting width: 15″
Maximum cutting height: 6″
Minimum stock thickness: 3/16″
Minimum stock length: 6″
Maximum depth of cut: 1/8″
Feed rate: 16 FPM & 20 FPM
Cutterhead diameter: 3″
Cutterhead inserts: 52
Cutterhead flutes: 4
Infeed rollers: solid serrated steel
Outfeed rollers: knurled steel
Table size with extension wings: 15″ x 48″
Dust port: 4″
Approximate shipping weight: 581 lbs.
CSA certified
Features:
Helical cutterhead with 52 indexable carbide inserts for superior finish
Two-speed gearbox for versatile feed rates
Anti-kickback fingers for enhanced safety
Chip deflector directs chips into the dust hood
Precision-ground cast-iron table for stable and accurate work surface
Ball bearing return rollers for efficient production
NOTES:
🔥 10 BLADE PRO MACHINERY
📞 1‑833‑410‑2523
📞 1‑833‑4‑10BLADE
📸 IG: @10bladepromachine
📘 FB: facebook.com/10BladeProMachinery
🚚 Immediate Pickup — NO TAX – NO FREIGHT – NO REGRETS
Stored indoors. Unused. Sold exactly as received
