Description
Purchased at an auction, but decided to go a different route before getting it set up and wired in our shop. It worked when we purchased it earlier in 2026, but again, we haven't ran it at our shop. Looking to get it out of the way rather quickly, so make me an offer. Comes with the dowel insertion unit, but it did not have the connection hoses when we bought it.
Pickup in Columbia, MO only. We can help load onto a trailer. We do have the shipping brackets for it that made moving it rather easy.
Details copied from another source:
Special features and details
Travel distance of the axis:
X= 1475mm (grip)
Y=1550mm
Z= 225 mm
Working area:
X= 3500 mm (unlimited)
Y= 950 mm
Z= 80 mm processable workpiece
Closed cable draw in X and Y axis
2nd reference fence cylinder for long workpieces Second stop cylinder for workpieces larger than X=1400mm
Fixed operating terminal on the left hand side of the machine
Optical status indicator of the machine
Main spindle 12 kW (S6) HSK F63
Drill head DH17 6H 1S
- 11 vertical spindles
- 6 horizontal spindles
- 1 slotting saw in X
Four-side formatting possible as standard
Length measurement of the workpiece in X and Y
4 position tool changer for use of aggregates
Controlled centralized extraction connection
Automatic central lubrication system
400 V / 3 Ph / 60 Hz
