Delta horizontal boring machine

Double spindle horizontal boring via pneumatic foot pedal operation.

Included are a dozen different size boring bits and adapters.

Other Specifications
Spindle: Accepts 7/8-14 RH TPI

Maximum Bit Diameter with Spindles at 3/4" on Center: 5/8"

Drill Stroke (Carriage Stroke): 3-7/8"

Minimum/Maximum Center Distance of Spindle: 3/4" to 3"

Air Requirement: 90 PSI

Table Travel to Center Of Bit: 3-1/2"

Maximum Material Thickness (Table to guard): 8-1/2"

Table Size: 15-3/4"x 9-7/8"
